- Leading Manufacturer
- of Steel Double Layer Bobbin
- Address
- Valsad
Steel Process Drum
| Feature | Description |
|---|---|
| Structure | Two layers of wire are wound—one on the core, the second over the first—designed to maintain spacing and prevent short circuits. |
| Materials | Typically plastic, ceramic, or metal, chosen based on thermal and mechanical requirements. |
| Applications | Used in transformers, inductors, motor windings, relay coils, and precision wire winding. |
| Flanged Edges | Prevents wire from slipping off the sides of the bobbin during winding or operation. |
| Layer Isolation | May include insulation between layers to avoid electrical contact and interference. |
| Tension Control | Important for maintaining consistent wire tension during winding for optimal inductance. |
| Wire Gauges | Supports fine wire gauges, typically AWG 32 or finer. |
| Example Dimensions | Core diameter: 10–30 mm, Flange diameter: 30–100 mm, Wire capacity depends on gauge and bobbin size. |
